One Stop Solution For Industrial Fans

Boiler (CFBC, Spent wash, TG, AFBC and Waste to Energy): ID/FD/PA/SA/FGR Fans
Core segments of Steel, Cement, Power (incl Co-generation) and Sugar Plants: Process and Auxiliary Fans
Chemical, Oil & Gas, Fertilizer, Glass, Ceramic etc.: ID/FD/CA Fans and Incinerator Blower
Textile & Industrial Ventilation.

Construction: Robust Design, SISW / DIDW casing, Overhung / Simply Supported impeller, Concrete (Short Height) / Steel (Full Height) Pedestal.

Impeller Type: Backward Curved, Backward Aerofoiled, Backward Straight Inclined, Backward Curved Radial Tipped, Straight Radial Shrouded, Straight Radial Open to suit various applications and mediums handled by Fan.
Accessories: Inlet Box (Low Pressure Drop Design), Various types of Electrically or Pneumatically actuated Dampers, aero-dynamic Evase, Flexible Connections, Silencers (Standard or High-End Design), Various Types of Filters, Piezometric ring (Flow Measurement), RTD, Vibration Monitoring System, Lubrication System (Stand alone or centralized), Grease Dispenser, Slow Turning Device, Electric Motor, Fan Control Systems and Inter Connecting Ducts (as a special case).

Special Features: Gas Tight Design with Labyrinth /Gland /Graphite /Mechanical Seals, Online Cleaning System for sticky dust, Anti-Wear Hardness Protection, Anti-Rotation Clutch and Special design to suit particular application.

Material: IS 2062 (grade A, B, C), SS 304, SS 316, SS 321, Duplex Steel, various Special High Temp-High Tensile Alloy Steel and many others to suit application.

Drive: Through Flexible Coupling, Belt Drive, Direct on Motor, with or without Variable Frequency Drive. Fixed/Variable Speed Fluid Coupling, Gear Box, Customized Drive.

Installation: Concrete Foundation on Ground, Elevated Concrete Floors, Steel Platforms with or without Vibration Isolators.

Shop Testing: Mech Run Test (100% by default), Noise, Vibration, Perf Test as per IS, BS, ISO, AMCA Standards, Dynamic Balancing witness, Shaft Ultrasonic Testing (UT), Raw Material Test, Magnetic Particle Test (MPT), Radiographic Test (RT), Hardness Test- Wear Plates, Positive Material Identification (PMI) Test, Casing Leak Test (for Special Design) etc.

Logistic: Various Types of Surface Preparation /Painting, Packing, Transportation to site (Domestic & Overseas) in Assembled or Dismantled Condition to suit containerization.

Technical Documentation: GA Drawing, T-S Curve, Performance Curve, Tech Data Sheet QAP, Detailed Operation & Maintenance Instructions Manual for Fan & Bought Outs, Material Test Certificates, Guarantee Certificates. WPS-WPQ-PQR, CFD Analysis, Seismic Analysis, Life Cycle Cost Analysis, Endorsement of Bearing Selection and Vibration Isolator Selection by concerned suppliers, Assistance for Inter Connecting Ducts and any other Specific Requirement.

Commercial Documentation: Invoice, Delivery Challan, Detailed Packing List, LR and complete set of all relevant documents as per prevailing Acts.

Site Supervision: Assistance for Supervision of Installation, Commissioning, Testing and Training to Plant Operators, After Sales Troubleshooting, Site Balancing, AMC, Quick Delivery of Spare Parts (with 25 years of original fan supply records) and site assistance for retrofit/performance enhancement.
